Labconco Operating Instructions 5242600, Rev. B 4/27/07, ECO E275
1 of 20
LABCONCO CORPORATION 8811 Prospect Ave, Kansas City, MO 64132
(816) 333-8811, Fax (816) 363-0130, (800) 821-5525
Pressure Controller Operating Instructions
General Description
These operating instructions are designed for the operation of the Pressure Controller used with
Labconco’s Precise Glove Boxes. The Pressure Controller performs three automatic modes on
the glove box. First, it cycles the purging/filling process in the main glove box chamber and
transfer chamber up to 199 cycles. Second, it regulates vacuum/pressure between -5 and +5
inches of water gauge in the main glove box chamber through the glove box pressure control
program mode. Third, it regulates vacuum in the transfer chamber between 0 and -29 inches of
mercury during the purging/filling process.
Models covered in these operating instructions:
5238600, Glove Box Pressure Controller, 100/115 volt, 50/60Hz
5238601, Glove Box Pressure Controller, 230 volt, 50/60Hz
