Labconco FreeZone and FreeZone Plus 6, 12 and 18 Liter Freeze Dry Systems 79600 Series - Manual (Page 74)

70
Appendix D: Freeze Dryer Accessories
Product Service: Domestic 1-800-522-7658, International 816-333- 8811
PART # DESCRIPTION
7948030 Stoppering Tray Dryer
230V, 50 Hz, three shelves, 600 square inches of area, provides
temperature control and stoppering under vacuum.
7948040 Stoppering Tray Dryer
230V, 60 Hz, three shelves, 600 square inches of area, provides
temperature control and stoppering under vacuum.
7726500 6 Port Manifold for use with Stoppering Tray Dryer
Mounts between the Stoppering Tray Dryer and the base unit and
provides 6 freeze dry valves.
7537800 Cable
Connect the RS232 output from the Freeze Dryer (or Freeze
Dryer/Tray Dryer combination) to an IBM compatible computer with a
9-pin serial data port.
7537801 Cable
Connects the RS232 output from the Freeze Dryer (or Freeze
Dryer/Tray Dryer combination) to an IBM compatible computer with a
25-pin serial data port.
7761500 Isolation Valve
Mounts between the Stoppering Tray Dryer and the base unit which
provides a way to isolate the base unit vacuum system from the
Stoppering Tray Dryer vacuum system.
7390702 6L Baffle
Mounts in the collector chamber to increase ice holding capacity when
operating with vacuum control.
7390701 12L Baffle
Mounts in the collector chamber to increase ice holding capacity when
operating with vacuum control.
