56
Appendix A: Freeze Dryer Components
Product Service: Domestic 1-800-522-7658, International 816-333- 8811
Item Model Part No. Description
1 All 7690800 Lid Gasket - Collector
2 All 7532900 Lid Collector
3 All 7408400 Lid Gasket - Drying Chamber-Shell Freezer
4 All 7408300 Lid - Drying Chamber
6L 7403100 Lid - Shell Freezer
5 6L 7750607 Compressor 115V, 60 Hz
6L 7750606 Compressor 230V, 50 Hz
6L 7750605 Compressor 230V, 60 Hz
6L Cascade 7591805 Compressor 115V, 60 Hz Hi Stage
6L Cascade 7591805 Compressor 115V, 60 Hz Lo Stage
6L Cascade 7591806 Compressor 230V, 50 Hz Hi Stage
6L Cascade 7591806 Compressor 230V, 50 Hz Lo Stage
6L Cascade 7591807 Compressor 230V, 60 Hz Hi Stage
6L Cascade 7591807 Compressor 230V, 60 Hz Lo Stage
12L 7592001 Compressor 230V, 50 Hz
12L 7592000 Compressor 230V, 60 Hz
12L Cascade 7750606 Compressor 230V, 50 Hz Hi Stage
12L Cascade 7750606 Compressor 230V, 50 Hz Lo Stage
12L Cascade 7750605 Compressor 230V, 60 Hz Hi Stage
12L Cascade 7750605 Compressor 230V, 60 Hz Lo Stage
18L 7391801 Compressor 230V, 50 Hz
18L 7391800 Compressor 239V, 60 Hz
6 6L 7591800 Compressor 115V, 60 Hz Shell Freezer
6L 7591801 Compressor 230V, 50 Hz Shell Freezer
6L 7591802 Compressor 230V, 60 Hz Shell Freezer
7 6L 7953800 Motor Fan 115V
All 7953801 Motor Fan 230V
8 All 1302300 Switch
9 All 7403500 Label Control Panel
All 7403501 Label Control Panel with Purge
All 7403502 Label Control Panel with Purge and Shell Freezer/Drying Chamber
10 All 7445590 Printed Circuit Board Control
11 All 7448000 Printed Circuit Board RS232
12 All 7728000 Drain Plug
13 All 1643600 O Ring
14 All 7645904 Drain Hose
15 All 7373450 Vacuum Hose (Not Shown)
16 All 1336400 Power Cord 115V, 60Hz (Not Shown)
All 1336500 Power Cord 230V, 50Hz EU (Not Shown)
All 1342100 Power Cord 230V, 60Hz (Not Shown)
All 1332601 Power Cord 230V, 50Hz UK (Not Shown)
All 1332701 Power Cord 230V, 50Hz China (Not Shown)
17 All 7445400 Vacuum Sensor
18 All 7515300 Temperature Sensor - Collector (Not Shown)
19 6L 7515300 Temperature Sensor - Shell Freezer (Not Shown)
