24
Chapter 4: Using Your Freeze Dryer
Product Service: Domestic 1-800-522-7658, International 816-333- 8811
• Press SELECT until the desired units are flashing.
• Press MENU.
• The display will show:
Where YYY is the units selected above.
• Press SELECT until the desired vacuum operating level is
displayed. See “Setting the Operating Vacuum Level” for
guidelines.
• If “0” is selected, the vacuum control is disabled and the
vacuum level in the Freeze Dry System will be determined
by the capabilities of the vacuum pump.
• Press MENU.
• The display will show:
Press SELECT until the desired units are flashing is displayed.
Press MENU.
The display will show the following screen if the Freeze Dryer is
equipped with a Drying Chamber.
When Y is the units selected above.
• Press SELECT until the desired temperature is displayed.
• Press MENU.
• The display will show:
TEMPERATURE UNITS
°C °F
REFRIG TOTAL HOUR: XXXX
SERVICE HOUR: XXXX
VACUUM SET POINT
XXXX
YYY
DRYING CHAMBER SETPOINT:
XX Y
