Page 67

Product Service 1-800-522-7658

Appendix A:

Replacement Parts

The components that are available for your filtered enclosure are listed. The parts
shown are the most commonly requested. If other parts are required, please
contact Product Service.

Item

Qty.

Part Number

Description

3911000

Glass, Side (Short)

3965800

Glass, Side (Tall)

3965801

Glass, Side w/ hole (Tall)

3911900

Glass, Sash 2'

3911901

Glass, Sash 3'

3911902

Glass, Sash 4'

3967200

Glass, Sash 5'

3967201

Glass, Sash 6'

3911800

Sash Assembly, 2'

3911801

Sash Assembly, 3'

3911802

Sash Assembly, 4'

3966900

Sash Assembly, 5'

3966901

Sash Assembly, 6'

3905600

Lower Air Foil, 2'

3905601

Lower Air Foil, 3'

3905602

Lower Air Foil, 4'

3969200

Air Foil, 5'

3969201

Air Foil 6'

3907400

Bracket, Air Foil R.H. (Short)

3907401

Bracket, Air Foil L.H. (Short)

3969000

Bracket, Air Foil RT (Tall)

3969001

Bracket, Air Foil LT (Tall)

3907500

Stop, Sash R.H.

3907501

Stop, Sash L.H.

6916500

Latch, Sash

3906700

Bracket, Latch

1927403

Spring, Compression Latch

1893206

Screw, 8-32 x .38" Lg. Phillips Pan S.S. Type F

3973203

Gas Spring Assembly, 20 Lb., 4'

3973200

Gas Spring Assembly, 30 Lb., 5' or 6'

3776003

Bag, 2' – for Bag-In/Bag-Out on XPert

1 or 2

3776004

Bag, 3' or 6' – for Bag-In/Bag-Out on XPert

3776005

Bag, 4' – for Bag-In/Bag-Out on XPert

3776006

Bag, 5' for Bag-In/Bag-Out or XPert

1889316

Screw, 10-24 x 1.00 PH Phil S.S.

1912108

Washer, Plastic .194 ID. x .380 OD

7868402

Bushing, Spacer .31 x .63

1.9 Ft

6913700

Wiper, Sash Seal

11A

1936800

Bushing, Heyco closed 1.50 Dia.

11B

1934601

Bushing, Heyco w/ Flex Shutter 1.50 Dia.
