Chapter 7: Accessorizing Your Filtered Enclosure
Product Service 1-800-522-7658
57
Has a 1/4 hp or 1/3 hp adjustable belt drive motor and corrosion resistant epoxy
coated steel housing and wheel with blower inlet of 10" ID. Outlet dimensions are
5.5" x 10" OD.
Catalog #
HP
Description
CFM@RPM Ranges at Static Pressure (inches of H
2
0)
Std.
EP
.25"
.38"
.50"
.62"
.75"
.88"
1.00"
7068200
1/4
Remote Blower, 115V, 60
Hz, 4.4 A
540@800
410@800
350@870
390@970
7068300
1/4
Explosion Proof Blower
115V, 60 Hz, 4.5 A
720@950
760@1050
710@1060
620@1060
7068400
1/3
Remote Blower, 115V, 60
Hz, 6.1 A
760@1050
710@1060
620@1060
430@1060
460@1150
500@1220
7068500
1/3
Explosion Proof Blower,
115V, 60 Hz, 6.4 A
850@1130
825@1160
790@1190
770@1220
740@1260
640@1260
5.
Exhaust Dampers
Exhaust dampers allow adjustments required to maintain proper airflow for
roof-mounted blowers or house exhaust systems. This would primarily be
useful only for the XPert Filtered Balance Station, which does not have an
integral blower. The 2', 3', and 4' stations use 6" and the 5' and 6' stations
use 10".
Catalog #
Description
3924000
6" Epoxy Coated Steel In-Line adjustable damper
4724200
6" PVC In-line adjustable damper
5983400
10" PVC In-line adjustable
3776800
10" Airtight Damper (10" tall)
6.
Accessory Filters
HEPA Filter
HEPA Filter is 99.99% efficient on particles 0.3 micron and 5' and 6' have
two each.
Width
Catalog #
Size
2'
3707900
18" x 18" x 3.31"
3' or 6'
3707901
30" x 18" x 3.31"
4'
3707902
42" x 18" x 3.31"
5'
3707903
24" x 18" x 3.31"
Note – 39712xx, 39713xx & 39714xx Systems come with 6" Exhaust
Damper (3924000)
