Labconco XPert Filtered Balance Stations 3962622 User Manual
Page 59
Chapter 7: Accessorizing Your Filtered Enclosure
Product Service 1-800-522-7658
55
2.
Guardian™ 1000 Digital Airflow Monitor or Guardian™ LED Airflow
Monitor
The Guardian Digital 1000 Airflow Monitor or Guardian LED Airflow
Monitor allows you to continuously monitor airflow through the enclosure.
Either monitor is usually provided with the XPert enclosures.
Description
Order Part #’s
Individual Parts Required
Guardian Airflow Monitor
115V or 230V
1 ea.
3811500
Airflow Monitor Printed Circuit Board
1 ea.
3910700
Airflow Sensor w/ Connector
2 ea.
1885405
#6-32 x .31" Phillips machine screw to mount Airflow
Monitor Circuit Board
2 ea.
1891808
#6-32 x .50" Phillips thread cutting screw to mount
Airflow Sensor
Guardian Digital 1000
Airflow Monitor
115V or 230V
1 ea.
3908500 or
3908501
115V or 230V Guardian Digital Monitor, Airflow Sensor,
Sensor Cable, and 15 VDC power supply
1 ea.
7907802
Outlet Assembly, 125V w/male terminals
1 ea.
3926800
Label, Set – XPert Filtered Balance Systems & Stations
2 ea.
1910308
Lockwasher, Int. Star, Acid Resist. (Various Sizes)
2 ea.
1885616
Screw, Machine, 6-32 x 1, Oval (F), Phillips, Zinc, Black
2 ea.
1889406
Screw, Machine, 8-32 x 3/8, Pan, Phillips, Steel, Zinc
Add appropriate Front Panel with cutout to mount Digital 1000 Airflow
Monitor
1 ea.
3904803
2' Front Panel w/ cutout
or
1 ea.
3904804
3' Front Panel w/ cutout
or
1 ea.
3904805
4' Front Panel w/ cutout
NOTE: The cutout can also be made with a reciprocating saw and a 1/8" diameter
bit. The centerline of the cutout is located 3.3" from the left side and 4.2"
from the bottom. The 1/8" mounting holes are spaced 4.38" apart top to
bottom and centered over the cutout. The cutout dimensions are 2.43"
wide by 4.13" tall.
3.
Canopy Exhaust Connection for Ducting to Outside
Canopy Exhaust connects to the XPert Filtered Balance System with
integral motorized impellers from the top so the duct can be routed up and
outside the building. The Canopy Exhaust is available for 6" nominal duct
on 2', 3' and 4' sizes and 10" nominal duct on 5' and 6' sizes. A 5" Canopy
Exhaust is available to duct to a FilterMate Portable Exhauster. The
Canopy Exhaust Connection should be sealed to the top of the enclosure
with silicone sealant to prevent leaks. See Figure 3-3 and Figure B-3.
