Hanna Instruments HI 9910 User Manual
Page 10
10
Unplug the instrument from the power supply before
wiring and replacing the fuses.
24
25
24. Female BNC socket for combination pH electrode
25. 4-mm Banana socket for ground probe
18. 0 to 20 or 4 to 20 mA isolated output switch
19. Triple contact alarm in a Normally Closed (NC) or a Normally
Open (NO) position.
20. Powered dosage terminals (Relays)
21. 110/115V or 220/240V power configuration
22. Incoming power terminals
23. Fuses
BOTTOM CONNECTION
