1) Liquid Crystal Display (LCD)
2) Function keys
3) MENU key, to change the function key at the bottom of the display
4)

/ keys to manually increase/decrease the parameters or to scroll between

the parameter list

5) SETUP key, to enter SETUP mode
6) RANGE key, to switch between pH and mV range (HI 3220); pH, mV and ISE

range (HI 3221)

7) HELP key to enter/exit contextual help
8) CAL key, to enter calibration mode
9) ESC to escape the current mode, exit calibration, setup, help, etc.

HI 3220, HI 3221

FUNCTIONAL DESCRIPTION

Front view
