Multi-Format Scaler Switch with HDBaseT
8
On the audio output side, the SC-12BT also offers amplified speaker outputs.
capable of delivering 2x10 watts to 8 Ω or 2x20 watts to 4 Ω speakers.
4.0 Operation
The SC-12BT can be controlled with the front panel buttons, an on-screen
display in conjunction with IR remote, or from RS-232/Telnet commands.
4.1 Control via Front Panel
Front panel controls and indicators
The front panel is intuitive and easy to use. There are 12 individual back-lit
push buttons for each input. The button for the currently selected input is lit.
The output resolution
The output resolution (for all 3 outputs) is set via the RESOLUTION
pushbutton. Audio adjustments are also on the front panel (see section 3.4).
Note that through the RS-232/Telnet commands all or parts of the front panel
functions can be locked. This is useful if the SC-12BT is being controlled
using an external controller and inadvertent control from the front panel is to
be avoided. Please refer to the control command set for further information.
4.2 Control using the IR and OSD Menu
The SC-12BT includes an On-Screen Display menu which will allow the user
to adjust various functions. Utilize the included infrared remote in order to
navigate through the OSD (Pressing the Menu button will bring you back to
the previously selected section). The OSD of the unit allows adjustments in
three categories: Picture, Sound, and Settings.
The Picture menu is used to set specific
parameters including color temperature,
contrast, brightness, hue, saturation, sharpness,
and scale. This menu also offers the setting of
presets and advanced picture adjustment,
however some parameters are only available
depending on the specific input source.
