1.0 Introduction
The SC-12BT is a 12 input HD scaler that accommodates 4 HDMI, 4 VGA,
and 4 AV inputs.
Select any of the inputs by using the front panel push-buttons, IR, RS-232, or
IP commands. The selected source is scaled to a fixed user definable
resolution and simultaneously output in 3 convenient formats: VGA, HDMI,
and HDBaseT (class B for easy extension to 70m / 230ft on a single UTP
connection using compatible receivers or displays with built-in HDBaseT
inputs).
The SC-12BT provides comprehensive audio capabilities. HDMI audio is
extracted; VGA and AV inputs (Composite, S-Video, and YPbPr) have their
own audio inputs, two auxiliary audio inputs are also provided (balanced mic
and stereo line-level). Two front panel controls are provided for adjusting the
output volume, one for setting the audio level from the video input and another
one for the AUX input.
The overall audio (sum of the audio from the selected source and the AUX
audio) is embedded in the HDMI and HDBaseT outputs and also is available
on a pair of RCA jacks (stereo).
The unit also boasts a 20 watt internal audio amplifier for direct connection to
4 or 8 Ω speakers (10w per channel into 8 Ω or 20w per channel into 4 Ω).
2.0 Features
• 12 input Switcher: 4x HDMI, 4xVGA, 2xCV, 1xS-Video, 1x YPbPr
• 3 Simultaneous Outputs: VGA, HDMI, and HDBaseT™
• Scaler with User Settable Output Resolution
• User friendly and intuitive front panel design
• IR, RS-232 and IP Control
• English-Based ASCII Command Set (Telnet or RS-232)
• HDMI Audio Extraction and Embedding
• Balanced Microphone and Stereo Line Inputs
• Line level and HDMI embedded audio outputs
• 20 Watt Power Amp for direct connection to speakers
NOTE All 3 outputs show the same image. The product is not a matrix switch.
