Hall Research SC-12BT - Manual (Page 2)

Multi-Format Scaler Switch with HDBaseT
2
Table of Contents
1.0 Introduction ____________________________________________________________ 3
2.0 Features _________________________________________________________________ 3
2.1 Package Contents _______________________________________ 4
3.0 Installation ______________________________________________________________ 5
3.1 Connecting the Video Inputs ______________________________ 5
3.2 Connecting the Scaled Outputs ____________________________ 6
3.4 Audio Subsystem and Amplifier Connections _________________ 7
4.0 Operation _______________________________________________________________ 8
5.0 RS-232 and IP Control Commands ____________________________________ 10
6.0 Troubleshooting ________________________________________________________ 12
7.0 Specifications ___________________________________________________________ 13
TRADEMARKS USED IN THIS MANUAL
Hall Research and its logo are trademarks of Hall Research. Any other trademarks
mentioned in this manual are acknowledged as the property of the trademark owners.
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment generates, uses, and can radiate radio frequency energy and if not installed and
used properly, that is, in strict accordance with the manufacturer’s instructions, may cause
interference to radio communication. It has been designed to comply with the limits for a Class A
computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are intended to provide reasonable protection against such interference when the equipment
is operated in a commercial environment. Operation of this equipment in a residential area is
likely to cause interference, in which case the user at their own expense will be required to take
whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
