5.0 RS-232 and IP Control Commands
The SC-12BT can be controlled via the RS232 port with the provided cable, or
through Telnet Protocol via the TCP/IP terminal port # 8080. Use a DB9
Male-to-Female cable shipped with the scaler to connect it to the computer or
external control device. Below a list of settings and commands provided to
utilize these controls and set specific functions.
5.1 RS-232 Control
The RS-232 port on the box provides plug-in screw terminals for RX, TX and
Ground. If connecting to a PC (or USB to Serial converter) a DB9-F cable will
be required, one such cable terminated to a removable screw terminal is
provided.
Baud rate: 9600 Data bits: 8 Stop bits: 1 Parity bit: none
5.2 Telnet Control
The SC-12BT can also be controlled via Telnet protocol, and communicates
on port # 8080. As shipped the IP address of the unit is set to DHCP, meaning
that when connected to a network with a DHCP server, the IP address is
assigned by the DHCP server. This is done so you can the device get a valid IP
address on your particular network.
You can use the serial port (or Telnet session) to assign a new IP address to the
box or to enable/disable DHCP. Please refer to the IP configuration commands
in the ASCII command set
5.4 RS-232 and Telnet Command Set
1) Commands are Case Insensitive
2) Commands are terminated with CR (Hex 0D) & LF (Hex 0A) is ignored
3) Responses are sent to Serial port and to IP/Telnet port (if TCP client is present)
4) RS-232 baud rate: 9600 Data bits: 8 Stop bits: 1 Parity bit: none.
*** The following table is available as a pdf file from the product’s website
Command Response Notes
S SourceMute 1 SourceMute 1 Audio from AV Source Muted
S SourceMute 0 SourceMute 0 Audio from AV Source Unmuted
S SourceVol ZZ S SourceVol ZZ Set Source Volume to ZZ ( ZZ = 00 - 99)
S SourceVol Up X S SourceVol ZZ Increase AV Source volume by X ( X= 1 - 9 )
S SourceVol Down X S SourceVol ZZ Decrease AV Source volume by X ( X= 1 - 9 )
S Brightness ZZ S Brightness ZZ Set Brightness to ZZ ( ZZ = 00 - 99)
S Contrast ZZ S Contrast ZZ Set Contrast to ZZ ( ZZ = 00 - 99)
S Saturation ZZ S Saturation ZZ Set Saturation to ZZ ( ZZ = 00 - 99)
S Sharpness ZZ S Sharpness ZZ Set Sharpness to ZZ ( ZZ = 0 - 7)
Autovga Done Auto Adjust VGA input
S OSDMenu X S OSDmenu X X = [ 0 - Hide OSD Menu, 1 - Show OSD Menu ]
S OSD Left S OSD Left
S OSD Right S OSD Right
S OSD Up S OSD UP
S OSD Down S OSD Down
S OSD 1 S OSD 1 Executes the highlighted item on the OSD menu
