Model UVA-WP
4
1.2 Features
• Handles resolutions up to 1080p (HD YPbPr) or 1920x1440
(PC VGA) at any refresh rate
• Rugged, Reliable, Compact size fits in tight spaces
• No power supply needed for most installations
• Drive standard CAT5 cables to 1000 feet
• Transmit audio and video signals on one cable
• Standard EDID video resolutions pre-programmed
2. Installation
2.1 Package
Contents
The Model UVA-WP comes with the following items
• Wallplate with attached circuit board
• male-male VGA and 3.5mm Audio input cables (approx. 6 ft
long)
• A power supply
o For North America: a 110 VAC input, 6v, 300 ma
output adapter
o For Europe or Australia (parts with -E or -U): a
Universal input , with 6v output power supply
• A 2.5mm loose jack (can be used to attach the power supply
to the unit
• For Europe or Australia (parts with -E or -U): A retrofit, single
gang High Impact PVC electrical box with clamps (Hall
Research Part Number 920-WB-B114R-UPC)
