Wallplate VGA and Audio on UTP Transmitter
3
1. Introduction
1.1 General
The Model UVA-WP is a single-gang wall plate that can transmit PC
VGA video or HD analog component video (YPbPr) with audio up to
1,000 feet over a single Cat5/6/6e twisted pair cable.
In most installations for PC video extension, the unit does not require
connection of a power supply (it will draw power from PC video source
through HD15 connector with a VESA compliant VGA cable). This,
together with its shallow depth, makes installations a snap. For
convenience the rear of the unit features a standard RJ45 connector.
In instances where the input video is YPbPr (requires a 3 RCA to
HD15 adapter cable), or if your PC does not provide power on its pin
9 of HD15 connector (as required by VESA standard), then a power
supply will need to be connected to the UVA-WP.
Next to the RJ45 connector on rear of the unit is a 2-position screw
terminal for connection of a power supply if your installation requires
it. The package includes a 6v DC power supply that you can use to
attach to the unit if needed.
At the other end of the Cat5 cable, to convert the signal back to VGA
and Audio, you need a compatible receiver such as a Model URA
receiver. The remote receiver is not included and must be purchased
separately.
