8
3 Solar Collector and Hydraulic Connection Arrangement
1 4 5 ...
1 12 11 2 ...
Diagram 3.1
15025
15140
14915
6 and up to 12 max Collectors
THE HYDRAULIC FLOW MUST BE DIAGONAL
1-5 Collectors
THE HYDRAULIC FLOW CAN BE TOP AND BOTTOM OR DIAGONAL
1-3 max. Collectors
Solar Collector
The recommended collector arrangements are shown below.
Hydraulic Connections
It is recommended that the hydraulic connections should be
made as shown below.
Roof Pitch 22 0 -75 0
1 4 5 ...
Roof Pitch 15 0 -22 0
THE HYDRAULIC FLOW CAN BE TOP AND BOTTOM OR DIAGONAL
Diagram 3.2
TOP & BOTTOM DIAGONAL
DIAGONAL
15139
1 2 3 1 2 3
TOP & BOTTOM DIAGONAL
