4 installation – Glow-worm Clearly Solar System Hydraulics User Manual
Page 12
12
4 Installation
Diagram 4.3
14213
SOLAR COLLECTOR
BOILER
SOLAR COLLECTOR
CIRCUIT PUMP
AUTO AIR
SEPARATOR
MOTORISED
2 PORT VALVE
MOTORISED
2 PORT VALVE
FLOW
FLOW
HOT
WATER
CONNECTION
TUNDISH
THERMOSTAT
MIXER
FLUROCYL
DRAIN VALVE
RETURN
RETURN
EXPANSION
RELIEF
VALVE
(6.0 BAR)
PRESSURE
LIMITING VALVE
(3.5 BAR)
WITH LINE
STRAINER
COLD
WATER
SUPPLY
PUMP
EXPANSION
VESSEL
TEMPERATURE
AND PRESSURE
RELIEF VALVE
(95 °C, 7 BAR)
LEGIONNELLA
LOOP (optional)
