Key
1 Overheating safety (UFH shown, but can be underfl oor or radiators)
2 Hydraulic module
3 Heating circuit
4 Climapro2 RF programmable wireless room thermostat
5 Systempro control unit
6 Wireless outdoor sensor
7 EBus boiler
8 Heat pump electrical supply + protection (This must have it's own
single isolation)
9 Non-return valve (recommended to prevent burner ignition triggered
by thermo-siphoning)
10 EBus heat pump
11 Heat pump circuit fi lter (not supplied)
12 Glycol PRV discharge
A Heating circuit return
B Heating circuit fl ow
C Boiler circuit return
D Boiler circuit fl ow
E Heat pump circuit fl ow
F Heat pump circuit return
G Heat pump circuit safety valve discharge
Application conditions
- The Systempro control unit manages the operation of the
boiler, the heat pump and the module.
- The Systempro control unit manages up to 3 heating zones.
- Each wireless room thermostat can control a heating zone.
- The installation can be performed with a low-temperature
underfl oor heating (heating outlet temperature < 50°C) or low
temperature radiators (heating outlet temperature < 70°C).
e
Use 0.75 mm² section cables for the electrical
connections to the control unit.
Control unit settings
Description of main settings Setting
Diagram no. 10
Did you install a multizone kit ? No
Heating curves 0.1 - 1.5
Max. heating fl ow temperature 30°C < T < 70°C
Energy effi ciency ratio To be defi ned
