0020096317_01 - 02/11 - Glow-worm
- 11 -
Key
1 Heat pump controlled by On/Off contact
2 Heat pump circuit fi lter (not supplied)
3 Hydraulic module
4 Heat pump electrical supply + protection (This must have it's own
single isolation)
5 Heat pump control unit
6 Wireless outside sensor with solar panel
7 Systempro control unit
8 EBus Boiler
9 Climapro2 RF programmable wireless room thermostat
10 Heating circuit
11 Non-return valve (recommended to prevent burner ignition triggered
by thermo-siphoning)
12 Overheating safety (UFH shown, but can be underfl oor or radiators)
13 Glycol PRV discharge
A Heating circuit return
B Heating circuit fl ow
C Boiler circuit return
D Boiler circuit fl ow
E Heat pump circuit fl ow
F Heat pump circuit return
G Heat pump circuit safety valve discharge
Application conditions
- The Systempro control unit manages the operation of the
boiler, the heat pump and the module.
- The Systempro control unit manages up to 3 heating zones.
- The heat pump control unit is used as a setting tool.
- Each wireless room thermostat can control a heating zone.
- The installation can be performed with a low-temperature
underfl oor heating (heating outlet temperature < 50°C) or low
temperature radiators (heating outlet temperature < 70°C).
e
Use 0.75 mm² section cables for the electrical
connections to the control unit.
Control unit settings
Description of main settings Setting
Diagram no. 5
Did you install a multizone kit ? No
Heating curves 0.1 - 1.5
Max. heating fl ow temperature 30°C < T < 70°C
Energy effi ciency ratio To be defi ned
Heat pump control unit settings
• Refer to the heat pump installation notice to access the “after-
sales” parameters listed below.
Menu Function name Setting
112 Heating curves (*) 7 - 12
114 ECO heating mode (*) 1 - 20°C
(*) Refer to the correspondence table in the “Settings > Heating”
section.
