Page 3
● First Person View (FPV) – Can be connected to the Hornet - OSD, the flight data stack to video output,and
through the vodeo transmission system to send back, let you enjoy the fun of FPV. And it will be easier to
operate FPV with the functions of automatic balance, Fixed altitude and Heading lock flight and Auto Return To
Launch.
● Real time telemetry – Real time monitor the flying state, using the Data Radio to lengthen the remote
control distance , and you can change the flight height and flight parameter through the Ground control
system(GCS).
For more information, please refer to the FY-OSD and FY Data Radio manual.
3. DOS standard configuration
Standard configuration
●DOS control module *1;
●RC receiver connecting wires * 1;
●USB cable *1;
●4P Y cable*1;
●Velcro double sided tape * 2;
●Instruction manual * 1;
Optional accessory
●GPS module *1;
●Hornet OSD module;
●Data Radio;
●Remote Adaptor;
4. Technical Specification and working requirement
DOS module
Input voltage : 4.0 ~ 6.0 Volt;
Current draw : 50mA (5V);
Size : 47 x 30 x 11 mm;
Weight (excluding wires) : 25g;
Temperature range : -25 ° C ~ +70 ° C;
Maximum rate of rotation : ≤ 2000 °/s
GPS module
Input voltage : 3.0 ~ 3.3 Volt;
Current draw : 60mA (3.3V);
Size : 32 x32x 10 mm;
Weight (excluding wires) : 22g;
Temperature range : -25 ° C ~ +70 ° C;
