Page 13
Elevator moves down
Elevator
moves up
Nose Up
Nose Down
Down
Elevator Movement In Auto Stabilization Mode
Mode
● If the servo movement is incorrect, you can choose one of these ways to change the control movement as
follows:
1)Adjust it by using DOS setup software through a USB cable.
2)Roll elevator stick on either side of the maximum position of the remote control. On SW1 switch ABM to 3D
mode 6 times, time interval has to be less than 3 seconds as follows:
ABM→3DMode→ABM→3DMode→ABM→3DMode→ABM→3DMode→ABM→3D Mode→ABM→3D Mode,
there is a yellow lamp will light up once, it‘s done.
D. RUDDER CONTROL SURFACE MOVEMENT CHECK
● Turn your plane clockwise or counter clockwise to see the rudder movement below:
Turn left
Rudder moves to the right
Turn right
Rudder moves to the left
● If the servo movement is incorrect, you can choose one of these ways to change the control movement as
follows:
1) Adjust it by using DOS setup software through a USB cable.
2) Roll rudder stick on either side of the maximum position of the remote control. On SW1 switch ABM to
3D mode 6 times, time interval has to be less than 3 seconds as follows:
ABM→3DMode→ABM→3DMode→ABM→3DMode→ABM→3DMode→ABM→3D Mode→ABM→3D
Mode, there is a yellow lamp will light up once, it‘s done.
