Page 10
(4) If instead the red LED lights up bright and stays ON solid, then the vibration dampening is not enough. You
will need reduce the level of vibration on your aircraft, add additional dampening support or change the
installation location.
Too much vibration may cause abnormal condition
1. In the stabilized mode, the plane can‘t keep steady, may roll or pitch
or other abnormal conditions.
2.Unde r the stabilized mode, after flying a while, it will deviate the steady position, can‘t keep steady flying.
3. All the navigation modes with GPS can‘t work normally.
12. Switch channel setting
DOS needs two 3 way-switches to control flying: SW1 is used to set manual
mode, stabilized mode,and 3D mode. SW2 is used to set Auto Return To Launch
Mode mode, Fixed altitude and Heading lock flight Mode and Auto Circling Mode,
which can be set by DOS setting software.SW2 had priority to SW1,only when
SW2 switch to cancel(Null) positon ,the SW1 can work.
After setting, operator can ensure if it is correct by judging the color and
flashing situation of the indicator lights.
SW1 default setting state
Position 1 2 3
Servo signal output 900
～1200US
1200~1800US 1800~2100US
Function Manual mode Stabilized mode 3D mode
SW2 default setting state(other function can be set to the SW2 by DOS setting software)
Position 1 2 3
Servo signal output 900
～1200US
1200~1800US 1800~2100US
Function
Fixed altitude and
Heading lock flight
Mode
NULL
Auto Return To
Launch Mode
13. DOS installation Orientation
DOS support 4 installation Orientations(LOGO arrow to up, down left,right) default installation Orientation
is the level position, the side with logo is to up, the arrow in the logo is in the same orientation with the head of
the plane. If need change other installation orientation,you can through our DOS setting software.
