Fy-41ap connection summary, Quadcopter connection summary – FeiYu Tech FY-41AP User Manual
Page 7
Guilin Feiyu Electronic Technology Co., Ltd
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyudz.cn [email protected]
- 7 -
8
Can weld to power manager module for connecting the battery
and ESC
9
GPS extension wire
FY-41AP Connection Summary:
The following pictures display the rotation direction and serial number of each
motor. Each ESC should be connected to the FY-41AP S1 - S8 interface. Pay
attention once you‘ve chosen the control type, as the corresponding position motor
rotate direction has to be completely the same as in the picture. (If the motor rotate
direction is not correct then exchange any two of the three connection wires between
ESC and motor to change the motor rotate direction.)
