After each setting, do not forget the " Save parameters "
FAIL-SAFE setting
In order to realize auto return to home when your aircraft out of control, requires
your RC and RC receiver both have ―Fail Safe‖ function.
When the Failsafe remote control receiver doesn‘t receive a signal, it outputs a
default setting for the rudder. Most remote control models have a controlled set
runway protection system. Please refer to your remote control‘s manual to see if
your remote has this function.
Auto return to home when your aircraft out of control require you connect the
SW1 to RC receiver CH5 corresponding channel and adjust your RC to make RC
receiver CH5 channel output a out of control signal to make SW1 into RTH mode.
And adjust your RC to make RC receiver throttle channel output a out of control
signal to make throttle into hovering position.
If in debugging balanced mode, the following example is that of a Futaba remote
control T10CHG setting runaway protection. Go to the settings menu, then turn off the
power to the aircraft to avoid setting the motor to start without control.
First enter the remote control setup menu to find the set of "F / S"; into the F / S
menu, put the lever into the neutral position, carefully adjust the settings rudder to
maintain the status adjusted, put the throttle lever to the cruise throttle position, and
then put the CH5 cut to return mode . Then in all open channel F / S set the program,
as successfully shown below (usually set by using the ―PUSH‖ button)
After setting the aircraft is powered off, check if it has successfully entered the return
mode.
Pay attention to safety, to prevent the Failsafe motor rotation, met items cause
damage.
