Main Module Installation
FY-41AP module installation
 While installing, please keep FY-41AP horizontal and as close as possible to the
"Centre of gravity" (COG) of the aircraft. The module‘s orientation can be changed by
FY-GCS (Ground Control Station) system: arrow to front (default), back, left or right.
Please reset the ―install orientation‖ after you changed the install orientation.
 Efficient anti-vibration components are very important and to be used when installing.
You can use the included ‗vibration absorbing dampers‘ or your DIY equipment. Please
note: For Nitro planes, flying without using efficient ‗anti vibration damper‘s‘, will lead
to FY-41AP working abnormally.

The better the damping installation is, the better attitude control and GPS hovering
functions are.
 Each modules installation to a suitable position is conducive to further enhance the
performance of Hovering mode. Regarding 41AP module installation position, the
center of the aircraft should be as far away as possible from other objects that could
cause interference. The aim is to reduce the disturbance to the internal IMU position
sensors when the aircraft tilts or rotates. In addition, you also have to consider a very
important factor: reducing the interference to the 41AP internal magnetic sensor due to
positioning during installation. There will be interference to magnetic sensor, from
surrounding objects with a strong current, motor rotation, battery, etc. Keep potential
interfering objects as far away as possible during installation. Keeping these two factors
in mind, please find a suitable position for installation. For example, you can put the
FY-41AP module on a high place.
