Copper Auto Tests
Copper and VDSL2/ADSL2+ Multi-play Test Set
225
POTS Auto Test
Phone Book Parameters:
Phone Book Group allows you to select the Group # from a list of
phone book groups that include mW tone entries.
Milliwatt Tone Entry displays at least 1 mW tone entry number
from the selected Phone Book Group.
Quiet Line Entry displays the quiet line entry number from the
selected Phone Book Group.
The dialer will contact the above 2 phone numbers at specific points of
time while the test is running.
Volume button adjusts the volume level.
Threshold Settings button opens a new page that allows you to set the
POTS Auto Test threshold parameters.
Mute/Unmute Speaker button changes the speaker status.
Result displays the number dialed and its status, measurement values
of the multiple test parameters and their pass/fail status.
Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press
on a value to open a list box of options.
4. Press
to confirm the value.
