Multimeter Tests
Copper and VDSL2/ADSL2+ Multi-play Test Set 97
Voltage
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
Continuous DC Page
The Continuous DC function measures each pair,
displaying and updating results in real time, until you
stop the test. The last valid results then remain
displayed.
Continuous AC and Continuous DC are run
synchronously.
Press Start/Stop on the keypad to run the test.

Current Group is the current test group name, for
example Multimeter.

Current Test displays the test being measured.
Here you can switch to another test from the given list. However, this
action will terminate the ongoing measurement test.

Selected Pair allows you to select All Pairs or a single wire pair for
measurement.

Termination Resistance defines how much resistance the tester uses
to connect to the line and measure voltages.

Threshold Settings button opens a new page that allows you to set the
DC voltage thresholds for each pair.
