Multimeter Tests
Copper and VDSL2/ADSL2+ Multi-play Test Set 99
Current
Current
The Current test allows you to measure the AC/DC currents and frequency
in the loop.
Snapshot
The current Snapshot shows measured AC/DC results
for each lead combination. The parameters are as
follow:

Current Group is the current test group name, for
example Multimeter.

Current Test displays the test being measured.
Here you can switch to another test from the given
list. However, this action will terminate the
ongoing measurement test.

Selected Pair allows you to select All Pairs or a
single wire pair for measurement.

Termination Resistance is a read-only value of 430 Ω that defines how
much resistance the tester uses to connect to the line.

Threshold Settings button opens a new page that allows you to set the
AC/DC current thresholds for each pair.

Result displays a snapshot of the pass/fail status, DC current, AC
current and frequency (Hz) results for each selected wire pair.

Test Status displays the current state of measurement or an error
message.
