Available models – EXFO LFD-200 Live Fiber Detector User Manual
Page 8
Introducing the LFD-200 Live Fiber Detector
3
Available Models
Four different models are available, as explained in the table below:
Model
Description
LFD-201
Detects continuous signal or signal modulated at 270 Hz, 1 kHz,
and 2 kHz.
Comes with three interchangeable adapter heads: 250 μm,
900 μm, 3 mm.
LFD-202
Detects continuous signal or signal modulated at 270 Hz, 1 kHz,
and 2 kHz.
Displays the relative core power in the fiber (that is, between –
6 dbm and –40 dBm).
Comes with three interchangeable adapter heads: 250 μm,
900 μm, 3 mm.
LFD-202P
Detects continuous signal or signal modulated at 270 Hz, 1 kHz,
and 2 kHz.
Displays the relative core power in the fiber (that is, between
+14 dbm and –19 dBm).
Comes with three interchangeable adapter heads: 250 μm,
900 μm, 3 mm.
LFD-203
Detects continuous signal or signal modulated at 270 Hz, 1 kHz,
and 2 kHz.
Especially designed for ribbon fibers.
Comes with three interchangeable adapter heads: 3 mm, bare
ribbon, jacketed ribbon.
