EXFO FTB-1 User Manual
Page 62
Setting Up Your Unit
52
FTB-1
Adjusting Microphone and Speaker Volume
6c. Under Other Controls, select the 1 Microphone Boost check
box.
6d. Tap Close.
Note: Normally, you only have to select this option the first time that you adjust
the microphone volume (the option will be selected for all other users as
well). Once it is done, you can control the volume with the slider as
explained at the next step.
7. Under Microphone, use the slider to adjust the sound of your
microphone. Close the window when your settings are complete.
8. Tap OK to return to the Display & Sound window.
9. Tap
to return to the Mini Toolbox window.
