HPNA Tests 5
Enter Profile Name is the new name of the profile.
To save modifications made to a
CustomProfile:
1. Select Save as New Profile and create and save
a new CustomProfile name in the current
directory.
2. If the file with CustomProfile name already
exists in the current directory, you will be
prompted to overwrite it.
To cancel modifications made to a CustomProfile:
1. Select Cancel Modifications and reload the current profile with the default
profile.
2. Proceed with the previously selected action (Back/Home/Start).
Parameters
The Parameters tab allows you to configure
performance test parameters to run the HPNA test.
³
Packet Length is the length of the packet,
ranging from 1 to 1480. Default value is 1480.
³
Number of Packets is the number of packets
for the CERT test, ranging from 1 to 99,999.
Default value is 10000.
To select the performance parameters to
configure:
1. From the Configure Tests pane, press the F1, F2, or F3 key located just below
the Parameters tab to select it.
2. Press the up/down arrows to select the desired parameter.
3. Press
to open the list or modify the parameter.
4. In the list, press the up/down arrows to select the function or mode.
OR
Use the alphanumeric keypad to enter the value you want to specify.
5. Press to confirm the selection.
