Page 12
ENMET Corporation
MX42A C
ONTROL
8
Figure 6: Front View of MX42A Control
N
OTE
:
In some applications, slight electronic noise between the Sensor/Transmitter and the Control can cause
fluctuations in the display reading. These minor fluctuations are considered to be insignificant in terms of the
range, detection limit and alarm values of the gas being monitored.
MX42A
MX42A
MX42A
MX42A
Display/Operation
Yellow & Green LEDs
Alarm 1
Red LED
Alarm 2
Red LED
Alarm 3
Red LED
Fault/Calibration
Yellow LED
Display
Buzzer Switch
Test Switch
Channel
Switches
4
3
1
TEST
2
DEF
AL3
AL2
AL1
1
2
3
4
