Page 11
MX32 E
NGUARD
ENMET Corporation
7
Figure 5: MX32 C
ONTROL
Main Power and Channel Board
MX32 C
ONTROL
Fuse Table
F7
24v Input
1.25A Time delay
F9,F8
for 115
V
AC
Input
315mA Time delay
F9,F8
for 230
V
AC
Input
160mA Time delay
F11,F13 24v Output
400mA Time delay
Fuse 24v
Output Channel 1
Fuse 24v
Output Channel 2
Fuse 24v
Input
See Fuse Table
Fuse AC
Input
See Fuse Table
Fuse AC
Input
See Fuse Table
J1 J2
J3 J4 J5
J6 J7
J8 J9 J10
Sensitivity POT
channel 2
Relay RL2
AL2 Channel 1
Relay RL1
AL1 Channel 1
Relay RL2
AL2 Channel 2
Relay RL1
AL1 Channel 2
Sensitivity POT
channel 1
Zero POT
channel 1
Zero POT
channel 2
Fault Relay
DEF
Fault Relay
3-pin header
J103
J103
J110
J105
J107
Ch2, AL2 relay
3-pin header
J108
Ch2, AL1 relay
3-pin header
J11 J12
J13 J14
J15 J16 J17 J18 J19 J20 J21
115 / 220
V
AC
F7
F9
F8
F11
F13
