-22-
Materials List
2 2-Snap Wires
2 3-Snap Wire
1 4-Snap Wire
1 6-Snap Wire
1 Battery Holder (B1)
1 100 Ohm Resistor (R1)
1 Slide Switch (S1)
1 Press Switch (S2)
1 Speaker (SP)
1 Music Integrated Circuit (U1)
Build the circuit as shown.
Use the circuit diagram symbols to draw the circuit here.
When you close the slide switch, what happens? _____________________________________________________________
To simulate a doorbell, push the button on the press switch.
Do you need to hold the button down to keep the music playing? ___________________________
What kinds of toys do you think could have integrated sound circuits? _____________________________________________
Activity 13
Musical Doorbell
(ST
ANDING)
