TK Series Guidance System Operator’s Manual
Overview - 3
System Components
CMW
System Components
TK Tracker
TX Transmitter
TK Trackers are compatible with Ditch Witch 86B series beacons: 86B, 86Bv2, 88B, and 88BAT. However,
for the best performance use a TX series transmitter.
TD Remote Display
TD Displays are compatible with a Ditch Witch 8500TK tracker of the same region/country model.
Tracker
Available Transmitter Frequencies
Telemetry Radio
TK
29kHz
Bluetooth
®
TKD
29kHz, 12kHz
Bluetooth
®
, UHF Long Range
TKQ
29kHz, 12kHz, 20kHz, 1.5kHz
Bluetooth
®
, UHF Long Range
Transmitter
Available Transmitter Frequencies
Pitch Resolution
Output Power
TX
29kHz
1%
Low
TXH
29kHz
1%
High
TXQ
29kHz, 12kHz, 20kHz, 1.5kHz
1%
Configurable
TXQG
29kHz, 12kHz, 20kHz, 1.5kHz
0.1%
Configurable
Remote Display
Mounting Options
TD
In dash
TDR
On-dash, magnetic
