TK Series Guidance System Operator’s Manual
Controls - 27
TD, TDR
CMW
Buttons
1. Select/Send
2. Down
3. Up
4. Power/Menu
Item Description Notes
1. Select/Send Press to select item shown on screen.
When connected to TMS Plus or OGMS: Press to
send data for current pipe to TMS Plus or OGMS.
2. Down In Tracking Mode, press to delete the last stored pipe
information.
In Menu Mode, press to move selection down.
3. Up In Tracking Mode, press to recall the last stored pipe
information or to query the next pipe data from TMS
Plus.
In Menu Mode, press to move selection up.
e17om040w.eps
1 2 3 4
