TK Series Guidance System Operator’s Manual
Controls - 17
TK, TKD, TKQ
CMW
2. Fine gain
Course gain
Shows fine gain as a 10-segment bar. Press up arrow or down
arrow to adjust signal gain.
Shows course gain as a 2-segment bar:
• One bar displayed indicates shallow mode.
• Two bars displayed indicates deep mode.
To change from shallow
mode to deep mode, adjust
fine gain.
3. Bubble level Indicates horizontal and vertical tilt of tracker.
4. Message
display Displays information such as software version,
logging status, beacon temperature warning, and low
battery alert.
5. Logging
indicator Lights when logging function is active.
6. Bluetooth
connection
indicator Lights when Bluetooth connection is established.
7. Backlight
indicator Lights when backlight is on. To improve battery life, turn
off the backlight. See
“Settings Menu” on page 22.
8. Location
active
indicator Lights when tracker is connected to a GPS device
via Bluetooth wireless technology.
9. Telemetry
indicator Indicates tracker is transmitting signal.
10. Telemetry
channel
Displays telemetry channel selection.
11. Tracker
battery
indicator
Indicates amount of battery power remaining for the
tracker.
12. Clock Displays time. To set time, see “System
Menu” on page 23.
Item Description Notes
