ECO Thermal Imager
User Manual
As with all batteries, your Bullard rechargeable battery will experience a slow
drain of its charge during storage. The amount of drain varies widely based on
storage conditions. To ensure adequate battery life, charge each of your batteries
every two weeks or, for best performance, keep your ECO and spare battery
charged in your vehicle in the ECO Powerhouse truck mount charger accessory
(part number: ECLPOWERHOUSEE). If you are using a Powerhouse charger, follow
the instructions contained in the accompanying manual.
NOTE
Ensure that the charging base is receiving power from a source via either
the AC or DC power adapters. If you do not see the red LED illuminate when
you place a battery into the charger, the battery is not charging.
NOTE
New, fully charged NiMH batteries will provide a run time of more than three
hours. To extend the potential lifespan of your batteries, fully drain and
recharge each battery monthly. For best operational results, develop a clear
formalized plan for maintaining, charging, and replacing your batteries.
Retractable Strap
The ECO Thermal Imager fits easily into a turnout gear pocket for convenient
storage while crawling or working. Additionally, Bullard offers a retractable strap
that can be used with the ECO, so that it is always at the ready. The strap (part
number: ECLRETRACTE), purchased separately, can be mounted to a D-ring on your
turnout gear coat and connected to the D-ring on the ECO.
Care Instructions
The Bullard ECO Thermal Imager requires little maintenance. For best results,
after each use:
• Clean the outside of the unit with mild soap or detergent.
• Wipe the lens with a soft cloth.
• Clean the display with a soft cloth.
• Check screw tightness on cover display.
• Store your thermal imager in the optional truck mount or in the delivery case
provided.
• All thermal imagers should be maintained using a proper program.
Cleaning the Lens
The Bullard ECO lens is recessed in an impact resistant bezel. The lens can be
cleaned with a soft cloth and soapy water as required.
Replacing the Video Display Cover Window
The display cover (Figure 6) has a
scratch-resistant hard coating to
minimize marring. However, if heavy
scratching or gouging does occur, the
cover window can be replaced. To do
this, remove the four Phillips head
screws along the sides of the window.
Remove the plastic display cover
window and replace with a new one
(part number: ECLWINDOW). Do not
over-tighten.
Do not allow the metal contacts on the battery to come in contact with a conductive
surface, such as a metal table or another battery. While the ECO is equipped
with protective circuitry to prevent product damage, contact with conductive
surfaces can complete the battery circuit and cause the battery to overheat or
melt. Failure to observe this warning may result in permanent battery damage,
property damage and/or serious injury.
WARNING
The ECO Thermal Imager is extremely sensitive to intense, radiant heat
sources. Never point the ECO at the sun or any other source of extreme
radiant heat, as this could severely damage the thermal imager.
WARNING
Figure 6
Do not use solvents or paint thinners to clean your Bullard ECO Thermal Imager,
as they could permanently mar the surface or degrade the protective properties
of the casing.
Do not intentionally submerge the unit underwater or subject the unit to high-pressure
water. Follow care instructions described above.
Failure to observe these instructions may result in product damage. Any
damage caused by improper care is not covered under warranty.
CAUTION
Do not attempt to disassemble the Bullard ECO Thermal Imager. Disassembling
the unit voids all warranties. For your convenience, TORX head screws have been
used to mark all areas that are non user-serviceable.
The Bullard ECO is not certified as intrinsically safe. Failure to follow these
instructions could result in death, serious injury and/or product damage.
Thermal imaging is not a technology designed to replace current fire fighting
tactics. Rather, it is a tool that allows the firefighter to be more effective and to
make better decisions.
Firefighters should not stop using basic fire safety tactics. All firefighters should
receive proper training on the following topics: how thermal imagers work; the
uses and limitations of thermal imagers; image interpretation; and the safety
considerations for thermal imaging use.
WARNING
