OPERATION
SPEED button
1. The “SPEED” button is available for use if the unit is in “AUTO”, “HEAT”, “COOL”, or “FAN” mode.
2. If the unit is in any of the modes mentioned above, pressing the “SPEED” button on the wall controller
to change the air velocity as shown below:
3. If the unit is in “DEHUMIDIFY” mode, the fan speed will be set on “AUTO”, and the “SPEED” button will
be unavailable for use.
TEMP UP Button & TEMP DOWN Button
1. During “COOL” or “HEAT” mode: the temperature can be changed by pressing the “TEMP UP” or
“TEMP DOWN” buttons.
2. During any effective mode: the user can press the “TEMP UP” or “TEMP DOWN” buttons to increase or
reduce the target temperature; the target temperature range is 18°C - 22°C for heating and 22°C - 26°C
for cooling.
3. “TIMER” operation: There are three periods of time that can be set for one day; The user can press the
“TEMP UP” button to increase the temperature or press the “TEMP DOWN” button to decrease the
temperature
4. Selecting operating modes: There are four modes of operation for this option; press the “TEMP UP” or
“TEMP DOWN” to alter the temperature as above.
MULTI-DAY TIMER” Button
“TIMER” functions: Press the “MULTI-DAY TIMER” button to activate or cancel the set timer of a certain
day which is included in the weekly multi-days timer setting.
WEEK Button
1. Calendar setting: Press the “WEEK” button to set the week, and the icon will display from Monday to
Sunday circularly on the LED display screen.
2. Timer mode: Press the “WEEK” button to choose a certain day as a target for the timer setting, and the
screen will display from Monday to Sunday
MIN Button
1. Minute settings: Press the “MIN” button, and the number will display an integer from 0 to 59. If the user
presses and holds the button, the number will increase by 10 each second.
2. Timer: Press the “MIN” button to set the time, and the number will display an integer from 0 to 59.
LOW MEDIUM HIGH AUTO
