User ’s Manual
ECM-LX800D User ’s Manual 49
IDE Primary Master UDMA
IDE Primary Slave UDMA
Auto
Disabled
Ultra DMA implementation is possible only if
your IDE hard drive supports it and the
operating environment includes a DMA driver
(Windows 95 OSR2 or a third-party IDE bus
master driver). If the hard drive and the system
software both support Ultra DMA, select Auto to
enable BIOS support.
IDE DMA Transfer Access
Enabled
Disabled
This item allows to enable or disable DMA
(Direct Memory Access) support for all IDE
devices.
IDE HDD Block Mode
Enabled
Disabled
Block mode is also called block transfer,
multiple
commands, or multiple section
read/write. If the IDE hard drive supports block
mode (most new drives do), select Enabled for
automatic detection of the optimal number of
block read/writes per sector the drive can
support.
Onboard Serial Port 1
Onboard Serial Port 2
Disable
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Auto
Select an address and corresponding interrupt
for the first serial ports.
Serial Port 2 Mode
232
422
485
Select the mode of serial port 2.
UART Mode Select
IrDA
ASKIR
Normal
Select UART2 mode as standard serial port or
IR port.
RxD , TxD Active
Hi,Hi
Hi,Lo
Lo,Hi
Lo,Lo
This item allows you to determine the active of
RxD, TxD level.
IR Transmission Delay
Enabled
Disabled
This item allows you to enable/disable the IR
Transmission Delay.
UR2 Duplex Mode
Half
Full
Select the value required by the IR device
connected to the IR port. Full-duplex mode
permits
simultaneous two-direction
transmission. Half-duplex mode permits
transmission in one direction only at a time.
Use IR Pins
RxD2,TxD2
IR-Rx2Tx2
This item allows you to determine the pin
definition.
Onboard Parallel Port
Disabled
378/IRQ7
278/IRQ5
3BC/IRQ7
FDD Mode
Select a matching address and interrupt for the
physical parallel (printer) port.
Parallel Port Mode
SPP
EPP
ECP
ECP+EPP
Normal
Select an operating mode for the onboard
parallel port. Select Compatible or Extended
unless you are certain both your hardware and
software support EPP or ECP mode.
EPP Mode Select
EPP1.9
EPP1.7
Select EPP port type 1.7 or 1.9.
ECP Mode Use DMA 1, 3 Select a DMA channel for the port.
Watch Dog Timer Select
Disabled,
10, 20, 30, 40 Sec.
1, 2, 4 Min.
This option will determine watch dog timer
