User ’s Manual
ECM-LX800D User ’s Manual 11
1.5 System Specifications
System
CPU
Onboard AMD Geode LX800 @ 0.9 W 500 MHz
Note: Available in different CPU speeds by request
BIOS Award 4 Mbit Flash BIOS
System Chipset AMD Geode LX 800/CS5536
I/O Chip Winbond W83627HG-AW
System Memory Onboard 256MB DDR Memory, optional 512MB
SSD One CompactFlash Type I/II socket
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Expansion One PC/104 connector
I/O
MIO
1 x EIDE (Ultra DMA 100), 1 x RS-232,
1 x RS-232/422/485, 1 x K/B & Mouse, 1 x LPT
IrDA 115k bps, IrDA 1.0 compliant
USB 2 x USB 2.0 ports
DIO 8-bit GPIO
Display
Chipset AMD Geode LX800 with integrated graphics engine
Display Memory 8/16/32/64/128/254 MB frame buffer using system memory
Resolution
CRT mode: 1920 x 1440 @ 32 bpp (85 Hz)
TFT mode: 1600 x 1200 @ 16 bpp (60 Hz)
LVDS Single channel 18-bit LVDS, optional 24-bit LVDS
VGA/LCD Interface Support 18/24 bit TTL
Built-in Touch Screen (Optional)
Chipset PenMount 6000
Touch Screen Interface
With 9-pin 2mm box header (can be selected to support 4/5/8-wire touch
screen)
Audio
Chipset AMD Geode CS5536
AC97 Codec Realtek ALC203 supports 2 CH Audio
Audio Interface Mic in, Line in, Line out, Audio in
Ethernet
LAN 1 & 2 Dual Realtek RTL8101L
Ethernet Interface 100Base-Tx Fast Ethernet compatible
