Avalue ECM-LX800D User Manual
Page 35
User
’s Manual
ECM-LX800D User
’s Manual
35
DAT
Display Data Channel Data. Used as data signal to/from monitors with DDC
interface.
RED
Analog output carrying the red colour signal to the CRT. For 75 Ω cable
impedance.
GREEN
Analog output carrying the green colour signal to the CRT. For 75 Ω cable
impedance.
BLUE
Analog output carrying the blue colour signal to the CRT. For 75 Ω cable
impedance.
