Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x03 Char1 Char2 Char3 Char4 Char5 Char6 0x0D, 0x0A
• Ack
• Function
The computer shows the name of the LCD display
Char1 : The 1st character of the name
Char2 : The 2nd character of the name
Char3 : The 3rd character of the name
Char4 : The 4th character of the name
Char5 : The 5th character of the name
Char6 : The 6th character of the name
*The default value of the character of the name is 0xFF
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x03 ERR 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x03 0x00 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Get LCD Display Address
< 2.3 > Get Name
