Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x53 P.Loc 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Set PIP location
• Function
The computer adjusts the PIP position of the display
The PIP function may or not be available on a particular LCD display depending on the model selected
Available only when the PIP is in small or large size state
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x53 P.Loc 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Ack
P.Loc : The PIP location code for the LCD display
0x10 Upper Left
0x11 Upper Right
0x12 Lower Left
0x13 Lower Right
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x53 ERR 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
< 2.24 > PIP Location Control
