Austin Hughes MCS - Manual (Page 6)

UM-CV-751-MCS-Q114V1 www.austin-hughes.com
No. Type of Command Command Range of Value ( Decimal ) Wait ACK (ms)
1 CAN Bus Registry 0x01 -- 2,000
2 Get Address 0x02 -- 200
3 Get Name 0x03 -- 200
4 Get Power Status 0x04 0 ~ 1 200
5 Get Display Status 0x05 -- 200
6 Get Screen Status 0x06 -- 200
7 Get PIP Status 0x07 -- 200
8 Set Display ID 0x15 1 ~ 64 200
9 Set Display Name 0x16 -- 200
10 Show Display ID & Name 0x17 5 ~ 255 200
11 Volume Control 0x20 0 ~ 100 200
12 Mute Control 0x21 0 ~ 100 200
13 Input Source Select 0x22 -- 2,000
14 OSD Button Control 0x23 0 ~ 1 200
15 Infrared Remote Control 0x24 0 ~ 1 200
16 Sound Select Control 0x25 -- 200
17 Contrast Control 0x26 0 ~ 100 200
18 Brightness Control 0x27 0 ~ 100 200
19 Auto Adjust 0x28 0 5,000
20 Power Control 0x45 0 ~ 1 7,000
21 PIP Control 0x50 -- 200
22 PIP Source Select 0x51 -- 200
23 Main-PIP Swap Control 0x52 0 200
24 PIP Locate Control 0x53 -- 200
< Part 2 > Command
P.4
