Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x51 P.Sour 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Set PIP Source
• Function
The computer adjusts the PIP source of the LCD display
The PIP function may or not be available on a particular LCD display depending on the model selected
Available only when PIP function is ON
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Check-
sum
Footer
0x4D, 0x43,0x06 0x51 P.Sour 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Ack
P.Sour : The PIP source code for the LCD display
0x10 VGA
0x11 S-Video
0x12 Composite
0x13 DVI-D
0x14 HDMI
0x15 SDI
0x16 YPbPr
0x17 TV
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x51 ERR 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
< 2.22 > PIP Source Control
