UM-CV-751-MCS-Q114V1 www.austin-hughes.com
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x23 OSDB 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Set OSD Button
• Function
The computer switches the OSD button function ON /OFF
OSDB : The OSD membrane button control code for the LCD display
0x00 OFF
0x01 ON
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x23 OSDB 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x23 ERR 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
< 2.14 > OSD Button Control
P.18
