Austin Hughes MCS - Manual (Page 25)

UM-CV-751-MCS-Q114V1 www.austin-hughes.com
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x28 A.Adj 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Set Auto Adust
• Function
Auto adjusts the VGA picture position on the screen
Available only when input source is VGA
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x28 A.Adj 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Ack
A.Adj : The auto adjust code for the LCD display ( 0x00 )
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x28 ERR 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
< 2.19 > Auto Adjust Control
P.23
