AMT Datasouth PAL - Manual (Page 56)

_barcode: PDF-417
50
/FileId
/FI String. Range 1..50 characters. Specifies the data for the PDF-
417 “File ID” macro field. The bar code will not include the File
ID macro field if this parameter is not specified or an empty
string is specified. Default = Empty string (field not included in
bar code).
/FileName
/FN String. Range 1..200 characters. Specifies the data for the PDF-
417 “File Name” macro field. The bar code will not include the
File Name macro field if this parameter is not specified or an
empty string is specified. Default = Empty string (field not
included in bar code).
/FileSize
/FS Boolean. true instructs PAL to include the PDF-417 “File Size”
macro field within the bar code. false instructs PAL to not
include the field. Default = false.
/Height
/H Integer or fixed-point. Specifies the height, in current user units,
of the bars in each row of the two dimensional bar code. Default
value = 3 (0.5" / 12.7 mm with default CTM).
/NarrowWidth
/XWidth
/NW
/X Integer or fixed-point. Specifies the width, in current user units,
of the narrow bars drawn as part of the bar code. This is
generally referred to as the X dimension. Default value = 0.72
points (1/100” / 0.254 mm with default CTM).
/Rows
/R Integer. Range 0..90. Establishes either the absolute or
maximum number of data rows which comprise the bar code.
The SizeFixed parameter controls the selection between
absolute or maximum. Specifying Rows overrides the Aspect
parameter. Specifying Rows without Cols results in PAL
generating a bar code with the minimum number of columns
based on the specified number of rows. Default = Rows not
specified.
/SenderId
/SI String. Range 1..200 characters. Specifies the data for the PDF-
417 “Sender ID” macro field. The bar code will not include the
Sender ID macro field if this parameter is not specified or an
empty string is specified. Default = Empty string (field not
included in bar code).
/SizeFixed
/SF Boolean. true instructs PAL to treat the Rows and Cols values
as specifying the required size of the two dimension bar code.
This will force the bar code to be the specified size. false
instructs PAL to treat the Rows and Cols values as specifying
only maximum sizes for the respective dimensions of the two
dimensional bar code. Default = false.
/TimeStamp
/T Integer. Specifies a value for the PDF-417 “Time Stamp” macro
field. A value of -1 instructs PAL to automatically generate the
Time Stamp field value from the printer’s internal real-time
clock. Specifying -1 is only valid on PAL printers which include
internal real-time clock services. Default = Time Stamp field not
included in bar code.
