1-2-2) CONNECTOR PIN ARRANGEMENT
CN-1 (2 HEAD MONO)
1
SP-L
2
COMMON
3
SP-R
4
GND
CN-1 (4 HEAD MONO)
1
SP-L
2
COMMON
3
SP-R
4
GND
5
EP-R
6
COMMON
7
EP-L
CN-C
1
L/C MT (+)
2
L/C MT (–)
3
GND
4
CAM D
5
CAM C
6
CAM B
7
CAM A
CN-1 (4 HEAD HI-FI)
1
A-L
2
COMMON
3
A-R
4
SP-L
5
COMMON
6
SP-R
7
GND
8
EP-R
9
COMMON
10
EP-L
CN-D
1
CTL
2
CTL
3
AUDIO
4
AUDIO
5
ERASE
6
GND
CN-2
1
EVER 5V
2
CAPSTAN F/R
3
CAPSTAN FG
4
CTL-REF
5
CTL
6
I-LIMIT
7
CAPSTAN M/T 12V/18V
8
GND
9
IC GND
10
NON CONTACT
CN-B
1
FE HEAD
2
GND
CN-A
1
GND
2
DRUM SPD CTL
3
Vcc
4
DRUM FG
5
DRUM PG
6
NON CONNECT
7
NON CONNECT
❉ Capstan M/T Voltage of
No.7 is 12V for normal
model and 18V for HI-
REW model.
